6514-M- 38.6:1 24000Nm 75.1-90.1mm Output
Roegelberg Hydraulic Gearboxes
Ratio 38.6:1 | Nominal power (Pn): 13.0kW | Max Input Torque (M1max): 622Nm |
Max Output Torque (M2max): 24000Nm | Short Time Peak Torque (Mkss) 36000Nm|
Shaft diameter (mm): 75.1-90.1 |
Weight: 250 Kg
