K80 Ball And Clamp Bolt On - Screwed Version
Screwed K80® ball and coupling kit for Heavy Duty towing.
Conforms with European functional safety requirements for the approval of agricultural and forestry vehicles. Approval Status: VO (EU) 2015/208
NOTE: We have drawings for most make and models tractor units to make up a K80 tow plate
Connection Type | K80® pull ball coupling system |
Drilling Pattern (mm) | 120 x 40 |
Bore / Thread | M16 |
Locking | K80® Manual |
